型號 Model | TSC-030 | TSC-040 | TSC-050 | |
提籃尺寸 Test Basket Dimensions |
D | 170 | 180 | 230 |
W | 120 | 150 | 150 | |
H | 150 | 150 | 150 | |
外形尺寸 Overall Dimensions |
D | 1300 | 1300 | 1350 |
W | 1440 | 1470 | 1470 | |
H | 1950 | 1950 | 1950 | |
提籃承載能力 (kg) Basket Loading Capacity | 1.0 | 2.0 | 5.0 | |
高溫液槽溫度范圍 Hot Tank Temp. Range | +60℃~+200℃ | |||
低溫液槽溫度范圍 Cold Tank Temp. Range | -65℃~+50℃ | |||
高溫液槽預熱時間 Hot Tank Heating Time | +25℃~+180℃≤45min | |||
低溫液槽預冷時間 Cold Tank Cooling Time | +25℃~-60℃≤55min | |||
溫度沖擊范圍 Temp. Shock Range | -60℃~+180℃ | |||
提籃轉移時間 Basket Move Time | <10s | |||
試驗籃驅動方式 Basket Drive Type | 旋轉+升降(氣動)Rotating+Lifting(Pneumatic Drive) | |||
溫度恢復時間 Temp. Recovery Time | <5min | |||
溫度波動度 Temp. Fluctuation | ≤±0.5℃ | |||
溫度均勻度 Temp. Uniformity | ≤2.0℃ | |||
壓縮空氣 Compressed Air | 0.4~0.7MPa | |||
額定電壓 Nominal Voltage | AC380V±10%,50Hz | |||
功率 Power (kW) | ≤12.5 | ≤13.5 | ≤15.0 |
備注
1.設備性能在環境溫度+25℃,相對濕度65%RH下,無負載所測。The performance vulues refer to environmental +25℃ 65%RH,no loading.
2.外形尺寸未包含局部突出部分。The ledge is not included in the overall dimensions.
