可將硫化或熱塑性橡膠等產品在應變條件下,暴露于含一定濃度臭氧的空氣中和在規定溫度且無光線直接影響的環境中,檢測其耐臭氧龜裂、應力變化、延長率等性能及可靠性。

Ozone can expose vulcanized or thermoplastic rubber and other products to the air with ozone and in the environment with a specified temperature and without direct effect of light under strain conditions to test its such performance and reliability as resistance to ozone cracking, variation of stresses and elongation ratio.

ASTM D1149 ASTM D1171 ASTM D1325 ISO1431 GB7762 HG/T 2869 JIS K 6259



工作室尺寸Test Space Dimensions 700*800*900(D*W*H)(mm)
外形尺寸 Overall Dimensions 1840*1240*1150(D*W*H)(mm)
臭氧濃度 Ozone Concentration 低濃度Low Concentration:25~500pphm / 高濃度High Concentration: 25~1000pphm
臭氧精確度 Ozone Diviation ≤±5.0%F.S
溫度范圍 Temp. Range S1:RT~+65℃ / S2:+15℃~+65℃
溫度波動度 Temp.  Fluctuation ≤±0.5℃
溫度均勻度 Temp. Uniformity ≤2.0℃
濕度范圍 Humidity Range S1:45%±10% / S1:30%~95%RH(可控)
氣體流速 Air Flow Speed 8mm~16mm/s
樣架旋轉速度 Sample Frame Rotary Speed 1r~5r/min,可調Adjustable
動態拉伸延長率 Dynamic Tensile Elongation 0~50%±2%,可調Adjustable
動態拉伸頻率 Dynamic Stretch Frequency 0.5~1.0Hz(±0.025 Hz)
樣件夾具 Sample Holder 靜態拉伸裝置 / 動態拉伸裝置 Static / Dynamic
額定電壓 Nominal Voltage AC380V or 220V ±10%,50Hz
功率 Power 5.0(kW)
重量 Weight 320(kg)

備注
1.設備性能在環境溫度+25℃,相對濕度65%RH下,無負載所測。The performance vulues refer to environmental +25℃ 65%RH,no loading.
2.外形尺寸未包含局部突出部分。The ledge is not included in the overall dimensions.
